Pantera
Rubberized or metal anti-abrasive vertical axis pump for heavy-duty applications
The Pantera pump is specially designed to handle highly abrasive fluids under severe conditions such as those found in quarries, mines and the chemical industry. Their vertical axis configuration precludes the use of submerged bearings or seals, making them particularly suitable for use in tanks or wells.
These models are available in two rugged variants: one with a body and impeller made of abrasion-resistant superalloy to provide exceptional resistance to abrasion wear, and the other with protective rubber inner shells, ideal for prolonging pump life in extremely corrosive environments.
Coupling to the motor is by means of belts and pulleys, a solution that enables precise performance adjustment to adapt effectively to load variations. This flexibility ensures optimal and reliable operation even under the harshest conditions.
Pantera pump application fields
Marble
Granite
Aggregates
Recycling
Mining
AXIS: The pump is designed with a vertical shaft and sealed chamber bearings, sized to allow the lower part of the shaft to operate without supports immersed in liquid.
BODY: made of chrome cast iron or coated with anti-abrasive rubber.
IMPELLER: The impeller, a closed type, is made of chrome cast iron with hardness between 750 and 800 HB, or coated with anti-abrasive rubber.
OPTIONAL: it is possible to immerse the pump in custom height according to specific requirements.
